Customizable Moisture-proof Metal Carved Board For Movable Panel Houses

Brand Name:	HY
Model Number:	09
MOQ:	1 piece
Delivery Time:	3 days
Payment Terms:	Prepayment starting from 30%

Detail Information

Product Description

Detail Information

Place of Origin:

Tianjin,China

Style:

Modern

Waterproof Grade:

IP65. The Top And Joints Are Sealed With Ethylene Propylene Diene Monomer (EPDM) Rubber

Customization:

Customized As Needed

Application:

K Value ≤1.5W/(㎡ · K), And It Can Maintain An Indoor Temperature Difference Of ≤8℃ In An Environment Ranging From -10℃ To 40℃

Service Life:

15 Years

Fire Resistance Grade:

The Wall Panels And Floors Meet The B1 Grade Flame-retardant Standard

Folded Dimensions:

Length 6000mm× Width 2400mm× Height 1600mm

Packaging Details:

Packaging of individual items

Supply Ability:

1000m per day (in stock)

Highlight:

Moisture-proof Metal Carved Board

Customizable Metal Carved Board

Metal Carved Board For Movable Panel Houses

Product Description

Customizable Moisture-proof Metal Carved Board For Movable Panel Houses

Product Specifications

Attribute	Value
Style	Modern
Waterproof grade	IP65. The top and joints are sealed with ethylene propylene diene monomer (EPDM) rubber
Customization	Customized as needed
Application	K value ≤1.5W/(㎡ · K), maintaining ≤8℃ indoor temperature difference from -10℃ to 40℃
Service life	15 years
Fire resistance grade	Wall panels and floors meet B1 grade flame-retardant standard
Folded dimensions	6000mm (L) × 2400mm (W) × 1600mm (H)

Customizable Prefabricated Movable Panel Houses

An efficient solution for temporary housing that combines durability with practical performance.

Core Advantages: Lightweight Yet Durable

Our lightweight panel houses follow the principle of "reducing weight without compromising quality." Featuring high-strength lightweight steel frames and advanced composite panels, they offer:

30% lighter weight than traditional panel houses while maintaining structural stability
Modular design for easier transportation and installation, especially in challenging terrains
Environmentally friendly materials with moisture-proof and fire-resistant properties
Compliance with modern temporary building requirements for sustainability

Technical Specifications

Parameter	Specification
Main Material	Lightweight galvanized steel frame (1.2-1.5mm wall thickness) + 50mm lightweight sandwich panel (flame-retardant EPS core)
Standard Unit Size	5.9m (L) × 2.8m (W) × 2.7m (H) - expandable with multiple units (0.8-1 ton weight per unit)
Wind Resistance	Level 6-7 (upgradable to level 8 in reinforced version)
Fire Resistance	B1 level flame-retardant sandwich panels with fireproof-coated frames
Load Capacity	≥200kg/㎡ uniform load (suitable for office and accommodation use)
Installation Time	2-3 person team can assemble one unit in 8 hours
Transport Efficiency	3.5-ton truck can carry 5-6 disassembled units (vs. 3-4 traditional units)
Service Life	8-12 years for main structure, 4-6 years for sandwich panels

Ideal Applications

Mountain/High-Altitude Use: Maintenance houses for photovoltaic stations, high-altitude rest rooms - easy to transport and install
Temporary Mobile Needs: Film crew housing, event structures - can relocate with projects
Low-Load Sites: Rooftop offices, light industrial auxiliary buildings - reduces foundation pressure
Emergency Response: Disaster relief housing - quickly deployable by small vehicles

Frequently Asked Questions

Does the lightweight design affect wind resistance?

The standard version resists level 6-7 winds, while the reinforced version withstands level 8 winds through structural enhancements.

Can a single unit support electrical needs?

Pre-installed wiring connects to 220V power, supporting lighting, air conditioning, and computer use.

Is it suitable for long-term outdoor use?

UV-treated panels withstand 3-5 years outdoors without significant aging (extendable with maintenance).

What ground preparation is needed?

Requires only flat ground or simple wooden boards - adapts to various terrains.

How does cost compare to traditional units?

10-15% higher initial cost but 40% savings in transport/installation for better overall value.
